Zebra ZT230 label printer Thermal transfer 203 x 203 DPI 152 mm/sec Wired
- Thermal transfer
- 203 x 203 DPI
- Maximum printing width: 10.4 cm Print speed: 152 mm/sec
- Built-in barcodes: 1D, 2D, Code 128 (A/B/C), Code 39, Code 93, EAN13, EAN8, Industrial 2/5, Interleaved 2/5, MaxiCode, PDF417, POSTNET, TLC39, UPC-A, UPC-E
- Connectivity technology: Wired
- USB port
- Display: LCD
- 9.1 kg
ZT230 Industrial Printer
The durability of a metal frame and cover with an icon based LCD graphical user interface and larger ribbon capacity for long lasting use in demanding environments.
Zebra incorporated extensive customer feedback, as well as the legacy of our industry leading Stripe and S4M printers, to create the new ZT200 Series family of printers with elegant space-saving design, effortless setup, intuitive user operation, and ease of service and maintenance.
SIMPLIFIED OPERATION AND OUTSTANDING VALUE
The ZT200 series is designed to simplify and shorten servicing and consumable replacement time. The easy tool-less platen and print head removal makes it easy for operators to maintain the printer. The side loading supplies path enables simplified media and ribbon insertion and color coded media path clearly directs media and ribbon threading.
COMPACT FOOTPRINT FITS WHERE SPACE IS AT A PREMIUM
The ZT200 Series printer’s compact design, when closed and opened, fits easily in constrained work areas. The ergonomic Bi-fold door requires only 4” (102mm) of door swing room. This reduces the printer height making it ideal for placement under a shelf or against another item.
| Printing |
| Maximum printing width |
10.4 cm |
| Print speed |
152 mm/sec |
| Maximum resolution |
203 x 203 DPI |
| Print technology |
Thermal transfer |
| Paper handling |
| Maximum media length |
3.99 m |
| Media thickness |
0.076 – 0.025 mm |
| Maximum label width |
11.4 cm |
| Maximum label length |
0.991 m |
| Maximum media length (imperial) |
157″ |
| Media thickness (imperial) |
0.003 – 0.01″ |
| Ribbon length |
450 m |
| Ribbon width |
11 cm |
| Ports & interfaces |
| Optional connectivity |
Ethernet, Wireless LAN |
| RS-232 ports |
1 |
| Parallel ports quantity |
1 |
| USB 2.0 ports quantity |
1 |
| USB port |
Yes |
| Wi-Fi |
No |
| Ethernet LAN |
No |
| Connectivity technology |
Wired |
| Performance |
| Certification |
IEC 60950, EN 55022 B, EN 55024, EN 61000-3-2, EN 61000-3-3, cTUVus, CE, FCC-B, ICES-003, VCCI, C-Tick, NOM, S Mark, CCC, GOST-R, KCC, BSMI |
| Built-in barcodes |
1D, 2D, Code 128 (A/B/C), Code 39, Code 93, EAN13, EAN8, Industrial 2/5, Interleaved 2/5, MaxiCode, PDF417, POSTNET, TLC39, UPC-A, UPC-E |
| Flash memory |
128 MB |
| Internal memory |
128 MB |
| Design |
| Housing material |
Metal |
| Display |
LCD |
| Built-in display |
Yes |
| Product colour |
Black, White |
| Power |
| Power requirements |
100 – 240 VAC, 47 – 63 Hz |
| Operational conditions |
| Operating temperature (T-T) |
0 – 40 °C |
| Storage temperature (T-T) |
-40 – 60 °C |
| Storage relative humidity (H-H) |
5 – 85% |
| Operating relative humidity (H-H) |
20 – 85% |
| Weight & dimensions |
| Weight |
9.1 kg |
| Height |
277 mm |
| Depth |
432 mm |
| Width |
242 mm |
| Logistics data |
| Harmonized System (HS) code |
84433210 |
| Technical details |
| Sustainability certificates |
ENERGY STAR |
