Zebra ZD500 label printer Direct thermal / Thermal transfer 300 x 300 DPI 102 mm/sec Wired Ethernet LAN
- Direct thermal / Thermal transfer
- 300 x 300 DPI
- Maximum printing width: 10.4 cm Print speed: 102 mm/sec
- Built-in barcodes: 2D, AZTECCODE, CODABAR (NW-7), Code 11, Code 128 (A/B/C), Code 39, Code 49, Code 93, Data Matrix, EAN128, EAN13, EAN8, GS1 DataBar, Industrial 2/5, Interleaved 2/5, MaxiCode, MicroPDF417, PDF417, POSTNET, QR Code, UPC-A, UPC-E
- Connectivity technology: Wired
- USB port Ethernet LAN
- Display: LCD
- 2.2 kg
Bringing Link-OS® environment capabilities to the Desktop, the ZD500 supports powerful applications for intuitive use and management. Delivering top-quality performance in the most demanding applications, it boasts a standard set of advanced features and supports both direct thermal and thermal transfer printing.
– Tool-less printhead and platen replacement;
– OpenACCESS™ for easy media loading;
– Quick and easy ribbon loading;
– Simplified calibration of media;
– Quad connectivity: USB, Parallel, Serial, and Ethernet;
– Real-time clock;
– LCD User Interface;
– Zebra E3 Printhead Energy Control;
– ENERGY STAR® qualified;
– Link-OS™enabled;
– Print Touch™ app;
– Unicode compliant for multi-language printing;
– 16 resident expandable ZPL II® bitmap fonts;
– Two resident scalable ZPL fonts;
– Auto-switching 100-240V power supply;
– Head-up sensor;
– Standard tear-off mode feature;
– 3″ media core adaptor;
– Zebra printer drivers for Windows™.
| Printing |
| Maximum print height |
99 cm |
| Maximum printing width |
10.4 cm |
| Print speed |
4 lpm |
| Maximum resolution |
300 x 300 DPI |
| Colour |
No |
| Print technology |
Direct thermal / Thermal transfer |
| Paper handling |
| Maximum media length |
99 cm |
| Media thickness |
0.08 – 0.305 mm |
| Supported paper width |
33.8 – 109.2 mm |
| Maximum label width |
10.8 cm |
| Maximum label length |
0.99 m |
| Maximum roll diameter |
12.7 cm |
| Core diameter |
1.27 cm |
| Ribbon length |
74 m |
| Ribbon width |
10.9 cm |
| Ports & interfaces |
| RS-232 ports |
1 |
| Parallel ports quantity |
1 |
| USB 2.0 ports quantity |
1 |
| USB port |
Yes |
| Wi-Fi |
No |
| Ethernet LAN |
Yes |
| Connectivity technology |
Wired |
| Performance |
| Built-in barcodes |
2D, AZTECCODE, CODABAR (NW-7), Code 11, Code 128 (A/B/C), Code 39, Code 49, Code 93, Data Matrix, EAN128, EAN13, EAN8, GS1 DataBar, Industrial 2/5, Interleaved 2/5, MaxiCode, MicroPDF417, PDF417, POSTNET, QR Code, UPC-A, UPC-E |
| Flash memory |
256 MB |
| Internal memory |
128 MB |
| Design |
| Display |
LCD |
| Built-in display |
Yes |
| Product colour |
Black |
| Power |
| AC input frequency |
50 – 60 Hz |
| AC input voltage |
100 – 240 V |
| Power consumption (printing) |
100 W |
| System requirements |
| Windows operating systems supported |
Yes |
| Operational conditions |
| Operating temperature (T-T) |
4.4 – 41 °C |
| Storage temperature (T-T) |
-40 – 60 °C |
| Storage relative humidity (H-H) |
5 – 90% |
| Operating relative humidity (H-H) |
10 – 90% |
| Weight & dimensions |
| Weight |
2.2 kg |
| Height |
191 mm |
| Depth |
254 mm |
| Width |
193 mm |
| Packaging content |
| Drivers included |
Yes |
| Quick start guide |
Yes |
| Cables included |
AC, USB |
| Technical details |
| Sustainability certificates |
ENERGY STAR |
| Other features |
| LED indicators |
Yes |
| Cabling technology |
10/100Base-T(X) |
