Viewsonic PG707X data projector Standard throw projector 4000 ANSI lumens DMD XGA (1024×768) White
- Presentation Standard throw projector White
- DMD 4000 ANSI lumens
- Lamp 6000 h
- XGA (1024×768) 22000:1
- Screen size compatibility: 762 – 7620 mm (30 – 300″) Number of colours: 1.07 billion colours
- Focus: Manual Zoom capability
- Ethernet LAN
- Built-in speaker(s) 10 W
- AC 280 W
The ViewSonic® PG707X projector features 4,000 lumens, XGA 1024×768 native resolution, an intuitive, user-friendly design, and a sleek white chassis. Exclusive SuperColor™ technology offers a wide color gamut for beautiful image production in nearly any environment. An energy-saving SuperEco™ feature reduces power consumption and extends the lamp life by up to 20,000 hours. A 10W speaker delivers incredibly clear and audible sound, while a top lamp door enables easy access for lamp maintenance. The PG707X is the ideal high brightness projector for use in both classroom and corporate settings.
SUPERCOLOR: AMAZING COLOR ACCURACY
ViewSonic’s proprietary SuperColor™ Technology features an exclusive 6-segment color wheel and dynamic lamp control capabilities, providing a wide color range and stunningly beautiful images.
BRIGHT IMAGES IN ANY ENVIRONMENT
Packed with 4,000 lumens and a high contrast ratio, this projector is guaranteed to produce bright images in nearly any environment – even in rooms with high ambient light.
ENERGY-EFFICIENT SUPERECO ™
SuperEco™ mode allows users to dim projection brightness by up to 70%, thereby reducing the lamp’s power consumption while extending lamp life—a great energy-saving design that lowers the total cost of ownership (TCO).
NETWORK MONITORING & CONTROL
IT admin can monitor, schedule, and manage the projector remotely, as well as receive projector status alerts, with the integrated Crestron® e-Control™ system and RoomView Express™ management software. Because this projector is Crestron® and AMX® certified, IT admin can control and monitor the projector for any size campus or enterprise.
CONVENIENT MOUNTING FLEXIBILITY
A 1.3x optical zoom lens provides more mounting flexibility over a standard lens so you can place your projector where you want and still get big, vivid images. For a perfectly proportioned picture every time, horizontal/vertical keystone correction and a corner adjustment feature eliminate crooked and distorted images.
REDUCED INPUT LATENCY
This projector delivers smooth images without delay. Its ultra-low 16ms input latency provides faster frame-by-frame action.
VERSATILE CONNECTIVITY
HDMI, USB, and VGA connections provide the versatility to connect to a wide variety of computing and multimedia devices.
| Projector | |
|---|---|
| Keystone correction, horizontal | -40 – 40° |
| Keystone correction, vertical | -40 – 40° |
| Matrix size | 1.4 cm (0.55″) |
| Horizontal scan range | 15 – 102 kHz |
| Vertical scan range | 23 – 120 Hz |
| Number of colours | 1.07 billion colours |
| Projection distance | 0.9 – 12 m |
| Screen size compatibility | 762 – 7620 mm (30 – 300″) |
| Contrast ratio (typical) | 22000:1 |
| Projector native resolution | XGA (1024×768) |
| Projection technology | DMD |
| Projector brightness | 4000 ANSI lumens |
| Light source | |
|---|---|
| Lamps quantity | 1 lamp(s) |
| Lamp power | 203 W |
| Service life of light source (economic mode) | 20000 h |
| Service life of light source | 6000 h |
| Light source type | Lamp |
| Lens system | |
|---|---|
| Offset | 115% |
| Throw ratio | 1.51-1.97 |
| Zoom ratio | 2.0:1 |
| Zoom capability | Yes |
| Aperture range (F-F) | 2.59 – 2.87 |
| Focal length range | 16.88 – 21.88 mm |
| Focus | Manual |
| Video | |
|---|---|
| Supported graphics resolutions | 640 x 480 (VGA), 1920 x 1080 (HD 1080) |
| Supported video modes | 480i, 480p, 576i, 576p, 720p, 1080i, 1080p |
| Analog signal format system | NTSC, PAL, SECAM |
| Ports & interfaces | |
|---|---|
| AC (power) in | Yes |
| PC Audio out | Yes |
| PC Audio in | Yes |
| Serial interface type | RS-232 |
| USB 2.0 ports quantity | 1 |
| Composite video in | 1 |
| DVI port | No |
| HDMI version | 1.4 |
| HDMI connector type | Full-size |
| HDMI ports quantity | 2 |
| VGA (D-Sub) ports quantity | 2 |
| Network | |
|---|---|
| Wi-Fi | No |
| Ethernet LAN (RJ-45) ports | 1 |
| Ethernet LAN | Yes |
| Smart TV | No |
| Storage | |
|---|---|
| Card reader integrated | No |
| Features | |
|---|---|
| Number of OSD languages | 23 |
| On Screen Display (OSD) languages | Arabic, Simplified Chinese, Traditional Chinese, Czech, German, Dutch, English, Spanish, Finnish, French, Greek, Indonesian, Italian, Japanese, Korean, Polish, Portuguese, Russian, Swedish, Thai, Turkish, Vietnamese |
| On Screen Display (OSD) | Yes |
| HDCP | Yes |
| Noise level (economic mode) | 28 dB |
| Noise level | 32 dB |
| Interactive | No |
| Multimedia | |
|---|---|
| RMS rated power | 10 W |
| Built-in speaker(s) | Yes |
| Design | |
|---|---|
| Placement | Desktop, Ceiling |
| Product colour | White |
| Market positioning | Presentation |
| Product type | Standard throw projector |
| Display | |
|---|---|
| Built-in display | No |
| Power | |
|---|---|
| AC input frequency | 50 – 60 Hz |
| AC input voltage | 100-240 V |
| Power consumption (standby) | 0.5 W |
| Power consumption (typical) | 280 W |
| Power source | AC |
| Operational conditions | |
|---|---|
| Operating temperature (T-T) | 0 – 40 °C |
| Weight & dimensions | |
|---|---|
| Package weight | 3.56 kg |
| Package height | 297 mm |
| Package depth | 168 mm |
| Package width | 415 mm |
| Height | 110 mm |
| Depth | 218 mm |
| Width | 294 mm |
| Weight | 2.35 kg |
| Packaging content | |
|---|---|
| Cables included | AC, VGA |
| Manual | Yes |
| Remote control included | Yes |
| Logistics data | |
|---|---|
| Harmonized System (HS) code | 85286200 |
