Urban Factory TCD45UF laptop dock/port replicator Wired USB 3.2 Gen 1 (3.1 Gen 1) Type-C Black
- USB-C: 100 W power / 550 mm cable
- Single Display Port: 4K/30Hz max.
- Single HDMI port: 4K/30Hz max.
- Single VGA port: 2K/60Hz max.
- USB-A 3.0 ports: 5 Gbps
- USB-A 2.0 ports: 480 Mbps
- RJ45: Gigabit Ethernet 1000 Mbps max
- Card readers: SD / TF (MSD) up to 2 TB
- Jack plug: 3.5 mm Stereo TRRS 4-pole
USB-C 4K DOCKING STATION MULTI-STREAM
The design of the HUBEE MINI docking station is slim and compact to provide natural heat dissipation, it incorporates a heavy-duty cable that offers great durability. This MST docking station supports triple display for computers compatible with USB-C video alternate mode. It supports resolution up to 1080p and if only one DP or HDMI display is connected, the display will reach 4K 30Hz resolution. The USB-A ports of the docking allow you to expand the use of USB peripherals such as an external hard drive, keyboard, mouse, headphones or even an optical drive. The integrated Gigabit Ethernet port will allow you to quickly download photos, videos, music or other files. To use it easily, the HUBEE MINI is Plug & Play, you will not need to install any external drivers or software.
| Ports & interfaces |
| Combo headphone/mic port |
Yes |
| DisplayPort version |
1.2 |
| DisplayPorts quantity |
1 |
| VGA (D-Sub) ports quantity |
1 |
| HDMI version |
1.4 |
| HDMI ports quantity |
1 |
| USB Power Delivery up to |
100 W |
| USB Power Delivery (USB PD) |
Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity |
1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
2 |
| USB 2.0 ports quantity |
2 |
| Host interface |
USB 3.2 Gen 1 (3.1 Gen 1) Type-C |
| Connectivity technology |
Wired |
| Network |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Ethernet LAN (RJ-45) ports |
1 |
| Ethernet LAN |
Yes |
| Performance |
| Country of origin |
China |
| LED indicators |
Yes |
| Plug and Play |
Yes |
| Number of displays supported |
3 |
| Maximum refresh rate |
30 Hz |
| Maximum digital resolution |
3840 x 2160 pixels |
| HD type |
4K Ultra HD |
| Data transfer rate |
5 Gbit/s |
| Maximum memory card size |
2 TB |
| Compatible memory cards |
MicroSD (TransFlash), SD |
| Card reader integrated |
Yes |
| Product colour |
Black |
| Power |
| Power cable length |
0.55 m |
| Software |
| Linux operating systems supported |
Yes |
| Mac operating systems supported |
Yes |
| Windows operating systems supported |
Windows 10, Windows 7, Windows 8 |
| Weight & dimensions |
| Weight |
255 g |
| Height |
19 mm |
| Depth |
58 mm |
| Width |
206 mm |
