TieDex UK Yealink MVC Series MVC940
Yealink MVC Series MVC940 – Microsoft Teams rooms system
Basic Specifications
- Manufacturer’s Part Number
- MVC940-C5-008
- EAN
- 6938818307605
- Networking
- Network adapter – Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, 802.11ax, Bluetooth 5.2
- Video Input
- Digital video camera – line-out, USB 2.0
- Video Output
- Codec board
- Model
- Yealink MVC Series MVC940
- Device Type
- Microsoft Teams rooms system
- Input Device
- 11.6″ touchscreen (wireless, wired)
- Weight
- 12.1 kg
- Product Description
- Yealink MVC Series MVC940
- Kit Content
- 2 UVC84 USB PTZ cameras, AVHub, MTouch Plus touch panel, MCore Pro Mini-PC, RoomSensor, 2 x WPP30 wireless presentation pod
- PC Configuration
- 11th Gen Core i5, 8GB RAM, 128GB SSD
Video Output
- Type
- Codec board – external
- PC Configuration
- 11th Gen Core i5, 8GB RAM, 128GB SSD
Networking
- Type
- Network adapter
- Connectivity Technology
- Wireless, wired
- Data Link Protocol
- Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, 802.11ax, Bluetooth 5.2
Dimensions & Weight (Shipping)
- Shipping Width
- 93.5 cm
- Shipping Depth
- 41.3 cm
- Shipping Height
- 31.2 cm
- Shipping Weight
- 13.8 kg
Expansion / Connectivity
- Interfaces
- 3 x audio / video – HDMI output – 19 pin HDMI Type A ¦ 1 x network – Ethernet 10Base-T/100Base-TX/1000Base-T – RJ-45 ¦ 4 x SuperSpeed USB 3.0 – 9 pin USB Type A ¦ 1 x Yealink Mtouch port – RJ-45
Video Input
- Type
- Digital video camera (colour) – external
- Interface Type
- Line-out, USB 2.0
- Digital Video Capture Resolution
- 4K
- Video Modes
- 4K
- Optical Zoom
- 12
- Camera Mechanical Design
- Pan / tilt / zoom
- Features
- Security lock slot (cable lock sold separately), auto-framing, 80° diagonal field of view, 200° pan / 130° tilt
General
- Device Type
- Microsoft Teams rooms system
- Kit Content
- 2 UVC84 USB PTZ cameras, AVHub, MTouch Plus touch panel, MCore Pro Mini-PC, RoomSensor, 2 x WPP30 wireless presentation pod
- Weight
- 12.1 kg
Miscellaneous
- Compliant Standards
- CEC, EDID compatible
Software / System Requirements
- Software Included
- Microsoft Teams Rooms App, Windows 10 IoT Enterprise License, Windows 10 IoT Enterprise 64-bit, Yealink RoomConnect
Input Device
- Type
- 11.6″ touchscreen
- Connectivity Technology
- Wireless, wired
- Features
- Motion sensor, 10-point simultaneous touch, IPS screen, 1920 x 1080 resolution
