TieDex UK StarTech.com Gigabit Ethernet Single Mode Fiber Media Converter SC 40 km – 1000 Mbps (ET91000SM402) – fibre media converter – 1GbE
Convert and extend a Gigabit Ethernet connection up to 24.8 miles/40 km over Single Mode SC fiber. The ET91000SM402 1000 Mbps Gigabit Single Mode Fiber Media Converter SC (40 km) lets you extend a Gigabit Ethernet network over single mode fiber by up to 40km (25 miles).
A cost-effective solution for connecting a Gigabit Ethernet (1000Base-T) network to remote network segments over a (1000Base-LX/SX) fiber backbone, the GbE to SM fiber converter supports full Gigabit speeds for ideal network performance and scalability. Designed to offer a durable and convenient Ethernet to fiber solution, the Ethernet to SC Fiber converter features an all-steel chassis, and a simple plug-and-play installation with minimal configuration required.
For added versatility, this fiber media converter supports standalone operation, or installation into the 20 Slot, 2U Rackmount Chassis (ETCHS2U).
StarTech.com Gigabit Ethernet Single Mode Fiber Media Converter SC 40 km – 1000 Mbps (ET91000SM402) – Fibre media converter – 1GbE – 1000Base-LX, 1000Base-SX, 1000Base-T – RJ-45 / SC single-mode – up to 40 km – 1310 nm – for P/N: ETCHS2U, SVA12M2NEUA, SVA12M5NA
The ET91000SM402 1000 Mbps Gigabit Single Mode Fiber Media Converter SC (40 km) lets you extend a Gigabit Ethernet network over single mode fiber by up to 40 km (25 miles).
A cost-effective solution for connecting a Gigabit Ethernet (1000Base-T) network to remote network segments over a (1000Base-LX/SX) fiber backbone, the GbE to SM fiber converter supports full Gigabit speeds for ideal network performance and scalability. Designed to offer a durable and convenient Ethernet to fiber solution, the Ethernet to SC Fiber converter features an all-steel chassis, and a simple plug-and-play installation with minimal configuration required.
For added versatility, this fiber media converter supports standalone operation, or installation into the 20 Slot, 2U Rackmount Chassis (ETCHS2U).
Backed by a StarTech.com 2-year warranty and free lifetime technical support.
The ET91000SM402 1000 Mbps Gigabit Single Mode Fiber Media Converter SC (40 km) lets you extend a Gigabit Ethernet network over single mode fiber by up to 40 km (25 miles).
A cost-effective solution for connecting a Gigabit Ethernet (1000Base-T) network to remote network segments over a (1000Base-LX/SX) fiber backbone, the GbE to SM fiber converter supports full Gigabit speeds for ideal network performance and scalability. Designed to offer a durable and convenient Ethernet to fiber solution, the Ethernet to SC Fiber converter features an all-steel chassis, and a simple plug-and-play installation with minimal configuration required.
For added versatility, this fiber media converter supports standalone operation, or installation into the 20 Slot, 2U Rackmount Chassis (ETCHS2U).
Backed by a StarTech.com 2-year warranty and free lifetime technical support.
Basic Specifications
- Manufacturer’s Part Number
- ET91000SM402
- EAN
- 0065030846219
- Device Type
- Fibre media converter – RJ-45 / SC single-mode
- Designed For
- P/N: ETCHS2U, SVA12M2NEUA, SVA12M5NA
- Optical Wave Length
- 1310 nm
- Form Factor
- External
- Dimensions (WxDxH)
- 9.5 cm x 16 cm x 2 cm
- Localisation
- North America, United Kingdom, Europe
- Manufacturer Warranty
- 2-year warranty
- Enclosure Type
- External
- Power
- AC 120/230 V
- Max Transfer Distance
- 40 km
- Weight
- 0.6 kg
- Data Transfer Rate
- 1 Gbps
- Features
- Auto-uplink (auto MDI/MDI-X), half duplex mode, full duplex mode, rugged
- Cabling Type
- 1000Base-LX, 1000Base-SX, 1000Base-T
- Product Description
- StarTech.com Gigabit Ethernet Single Mode Fiber Media Converter SC 40 km – 1000 Mbps (ET91000SM402) – fibre media converter – 1GbE
- Model
- StarTech.com Gigabit Ethernet Single Mode Fiber Media Converter SC 40 km – 1000 Mbps (ET91000SM402)
- Data Link Protocol
- 1GbE
- Compliant Standards
- Plug and Play, FCC, RoHS
Networking
- Connectivity Technology
- Wired
- Cabling Type
- 1000Base-LX, 1000Base-SX, 1000Base-T
- Data Link Protocol
- 1GbE
- Data Transfer Rate
- 1 Gbps
- Optical Wave Length
- 1310 nm
- Max Transfer Distance
- 40 km
- Features
- Auto-uplink (auto MDI/MDI-X), half duplex mode, full duplex mode, rugged
Expansion / Connectivity
- Interfaces
- 1 x Ethernet 1000Base-T – RJ-45 female ¦ 1 x Ethernet 1000Base-LX/1000Base-SX – SC single-mode female x 2
Power
- Power Device
- External power adapter
- Voltage Required
- AC 120/230 V
Environmental Parameters
- Min Operating Temperature
- 0 °C
- Max Operating Temperature
- 60 °C
- Humidity Range Operating
- 10 – 90%
Compatibility Information
- Designed For
- P/N: ETCHS2U, SVA12M2NEUA, SVA12M5NA
General
- Device Type
- Fibre media converter
- Form Factor
- External
- Colour
- Black
- Localisation
- North America, United Kingdom, Europe
Manufacturer Warranty
- Service & Support
- Limited warranty – 2 years
Dimensions & Weight
- Width
- 9.5 cm
- Depth
- 16 cm
- Height
- 2 cm
- Weight
- 0.6 kg
Miscellaneous
- MTBF
- 65,000 hours
- Compliant Standards
- Plug and Play, FCC, RoHS
