TieDex UK Draytek Vigor 2865 – router – DSL modem – desktop
Draytek Vigor 2865 – Router – DSL modem 1GbE, PPP – WAN ports: 2
Basic Specifications
- Manufacturer’s Part Number
- V2865-K
- EAN
- 4710484741257
- Manufacturer Warranty
- 2-year warranty
- Weight
- 620 g
- Product Description
- Draytek Vigor 2865 – router – DSL modem – desktop
- Model
- Draytek Vigor 2865
- Dimensions (WxDxH)
- 24.1 cm x 16.6 cm x 4.6 cm
- Localisation
- United Kingdom, Ireland
- Features
- Firewall protection, 3G/4G USB Dongle Support, VPN support, reset button, load balancing, content filtering, DynDNS, bandwidth control, DHCP server, IPv6 support, IPv4 support, VLAN Tagging, ARP support, port-based VLAN, IP-MAC binding, port mirroring, DNS server, High Availability, IGMP proxy, IGMP snooping, file sharing, LAN-to-LAN bridging, GRE, IPSec NAT-T, failover protection, port triggering, DMZ support, ALG support, VPN passthrough, application filtering, URL filtering, Web Filtering, anti-spoofing protection, DoS attack prevention, QoS, ToS, DSCP support, DSCP based ToS, ACL support, Brute Force Protection, E-mail alert, SMS alert, Syslog support, tagged VLAN, keyword filtering
- Device Type
- Router – DSL modem
- Compliant Standards
- ANSI T1.413, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1x, UPnP
- Capacity
- VLANs supported: 16 ¦ Concurrent VPN tunnels: 32 ¦ NAT sessions: 60000 ¦ Concurrent SSL VPN tunnels: 16
- Performance
- VPN throughput (256-bit AES IPSec): 300 Mbps ¦ VPN throughput (SSL): 120 Mbps ¦ NAT throughput: 800 Mbps
- Data Link Protocol
- Ethernet, Fast Ethernet, Gigabit Ethernet, PPP
- Enclosure Type
- Desktop
- Routing Protocol
- Static IPv4 routing, static IPv6 routing, RIP, BGP, policy-based routing (PBR), GRE
- Network / Transport Protocol
- IPSec, DDNS, DHCP, PPPoE, PPTP, L2TP, IPv4, IPv6, DHCPv6, Bonjour, SMB, RTSP, FTP
- WAN Ports Qty
- 2
- VoIP Protocols
- SIP, H.323
- Remote Management Protocol
- Telnet, HTTP, HTTPS, SSH, TR-069, TFTP, SNMP 1, SNMP 2c, SNMP 3
- Digital Signaling Protocol
- VDSL2, ADSL2+, Vplus 35b, ADSL2, ADSL, VDSL
General
- Device Type
- Router
- Enclosure Type
- Desktop
- Connectivity Technology
- Wired
- Data Link Protocol
- Ethernet, Fast Ethernet, Gigabit Ethernet, PPP
- Performance
- VPN throughput (256-bit AES IPSec): 300 Mbps ¦ VPN throughput (SSL): 120 Mbps ¦ NAT throughput: 800 Mbps
- Capacity
- VLANs supported: 16 ¦ Concurrent VPN tunnels: 32 ¦ NAT sessions: 60000 ¦ Concurrent SSL VPN tunnels: 16
- Network / Transport Protocol
- IPSec, DDNS, DHCP, PPPoE, PPTP, L2TP, IPv4, IPv6, DHCPv6, Bonjour, SMB, RTSP, FTP
- Routing Protocol
- Static IPv4 routing, static IPv6 routing, RIP, BGP, policy-based routing (PBR), GRE
- Remote Management Protocol
- Telnet, HTTP, HTTPS, SSH, TR-069, TFTP, SNMP 1, SNMP 2c, SNMP 3
- Encryption Algorithm
- SSL, IKEv2, SHA-1, 256-bit SHA, DES, Triple DES, AES, MPPE
- Authentication Method
- RADIUS, XAUTH authentication, internal user database, LDAP, TACACS+, X.509 certificates
- Features
- Firewall protection, 3G/4G USB Dongle Support, VPN support, reset button, load balancing, content filtering, DynDNS, bandwidth control, DHCP server, IPv6 support, IPv4 support, VLAN Tagging, ARP support, port-based VLAN, IP-MAC binding, port mirroring, DNS server, High Availability, IGMP proxy, IGMP snooping, file sharing, LAN-to-LAN bridging, GRE, IPSec NAT-T, failover protection, port triggering, DMZ support, ALG support, VPN passthrough, application filtering, URL filtering, Web Filtering, anti-spoofing protection, DoS attack prevention, QoS, ToS, DSCP support, DSCP based ToS, ACL support, Brute Force Protection, E-mail alert, SMS alert, Syslog support, tagged VLAN, keyword filtering
- Compliant Standards
- ANSI T1.413, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1x, UPnP
- Built-in Devices
- Led panel
- Status Indicators
- DMZ, DSL, link/activity, USB, VPN, WAN
Communications
- Type
- DSL modem
- Digital Signaling Protocol
- VDSL2, ADSL2+, Vplus 35b, ADSL2, ADSL, VDSL
- Protocols & Specifications
- ITU G.993.2, ITU G.993.5, ITU G.992.1 (G.DMT) Annex A, ITU G.992.3 Annex A, ITU G.992.5 Annex A
- Max Transfer Rate
- 300 Mbps
Dimensions & Weight
- Width
- 24.1 cm
- Depth
- 16.6 cm
- Height
- 4.6 cm
- Weight
- 620 g
Miscellaneous
- Cables Included
- 1 x modem cable
- Localisation
- United Kingdom, Ireland
Manufacturer Warranty
- Service & Support
- Limited warranty – 2 years
Expansion / Connectivity
- Interfaces
- LAN: 5 x 10Base-T/100Base-TX/1000Base-T – RJ-45 ¦ WAN / LAN: 1 x 10Base-T/100Base-TX/1000Base-T – RJ-45 ¦ WAN: 1 x VDSL2 / ADSL2+ – RJ-11 ¦ USB 2.0: 2 x 4 pin USB Type A
Power
- Power Device
- External power adapter
Environmental Parameters
- Min Operating Temperature
- 0 °C
- Max Operating Temperature
- 45 °C
- Humidity Range Operating
- 10 – 90% (non-condensing)
Software / System Requirements
- OS Provided
- No operating system
Line Properties
- Framing Format
- ANSI T1.413
IP Telephony
- VoIP Protocols
- SIP, H.323
