TieDex UK Cisco Meraki MR28 – radio access point – entry level – Wi-Fi 6, Bluetooth – cloud-managed
Cisco Meraki MR28 – Radio access point – entry level – Wi-Fi 6 – Bluetooth – 2.4 GHz, 5 GHz – cloud-managed
Basic Specifications
- Manufacturer’s Part Number
- MR28-HW
- EAN
- 0810979019046
- Manufacturer Warranty
- Limited lifetime warranty
- Weight
- 272 g
- Product Description
- Cisco Meraki MR28 – radio access point – entry level – Wi-Fi 6, Bluetooth – cloud-managed
- Model
- Cisco Meraki MR28
- Dimensions (WxDxH)
- 20.2 cm x 12.4 cm x 2.58 cm
- Device Type
- Radio access point
- Form Factor
- External
- Performance
- Maximum data rate (5 GHz): 1201 Mbps ¦ Maximum data rate (2.4 GHz): 286 Mbps
- Frequency Band
- 2.4 GHz, 5 GHz
- Data Link Protocol
- IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac Wave 2, Bluetooth 5.0 LE, IEEE 802.11ax (Wi-Fi 6)
- Power Over Ethernet (PoE) Supported
- PoE
General
- Device Type
- Radio access point
- Width
- 20.2 cm
- Depth
- 12.4 cm
- Height
- 2.58 cm
- Weight
- 272 g
Miscellaneous
- MTBF
- 257,215 hours
- Compliant Standards
- CSA, VCCI, ICES-003, EN55024, CISPR 22, FCC Part 15 B, RSS-102, FCC Part 15 C, UL 2043, RoHS, FCC Part 2, AS/NZS 4268, FCC Part 15 E, EN 62311, EN 300 328, EN 50385, RSS-247, EN 301 489-1-17, EN 62479, EN 301 893, EN 55032, AS/NZS 2772, CB 60950, CB 62368, IFT, NOM-208, NCC LP0002
Manufacturer Warranty
- Service & Support
- Limited warranty – advanced replacement – lifetime
Networking
- Form Factor
- External
- Connectivity Technology
- Wireless
- Data Transfer Rate
- 1.5 Gbps
- Line Coding Format
- 1024 QAM
- Data Link Protocol
- IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac Wave 2, Bluetooth 5.0 LE, IEEE 802.11ax (Wi-Fi 6)
- Network / Transport Protocol
- IPSec
- Cloud-Managed
- Yes
- Frequency Band
- 2.4 GHz, 5 GHz
- Performance
- Maximum data rate (5 GHz): 1201 Mbps ¦ Maximum data rate (2.4 GHz): 286 Mbps
- Status Indicators
- Power, Boot State, firmware
- Features
- Firewall protection, VPN support, firmware upgradable, tunnelling, Wi-Fi Multimedia (WMM) support, Quality of Service (QoS), Maximum Ratio Combining (MRC), DiffServ Code Point (DSCP) support, Bluetooth Low Energy Beaconing, Unscheduled Automatic Power Save Delivery (U-APSD), beamforming technology, SU-MIMO technology, PMK Caching, guest access, layer 3 roaming, opportunistic key caching (OKC), VLAN Tagging, 2×2:2 MU-MIMO technology, packet aggregation, layer 2 roaming, Orthogonal Frequency Division Multiple Access (OFDMA), BSS Coloring, Target Wake Time (TWT), Enterprise Mobility Management (EMM), Mobile Device Management (MDM), Cisco ISE integration, layer 7 application traffic identification and shaping, global L7 traffic analytics, embedded location analytics reporting and device tracking
- Encryption Algorithm
- AES, TKIP, WPA, WPA2-PSK, WPA2-Enterprise, WEP, WPA3-Enterprise, WPA3-Personal, WPA3-Enhanced Open
- Authentication Method
- MS-CHAP v.2, EAP-SIM, EAP-TLS, EAP-TTLS
- Compliant Standards
- IEEE 802.1Q, IEEE 802.1p, IEEE 802.11b, IEEE 802.11a, IEEE 802.3af, IEEE 802.11g, IEEE 802.1x, IEEE 802.11i, IEEE 802.11h, IEEE 802.11e, IEEE 802.11n, IEEE 802.11k, IEEE 802.11ac, IEEE 802.11r, IEEE 802.11u, IEEE 802.11ax
Expansion / Connectivity
- Interfaces
- 1 x 1000Base-T (PoE) – RJ-45
Power
- Power Over Ethernet (PoE) Supported
- PoE
Environmental Parameters
- Min Operating Temperature
- 0 °C
- Max Operating Temperature
- 40 °C
- Humidity Range Operating
- 5 – 95% (non-condensing)
Aerial
- Antenna
- Internal
- Gain Level
- 6 dBi
Internet of Things (IoT)
- Internet of Things (IoT) Compatible
- Yes
- Communications Technology
- Bluetooth Low Energy (LE)
