TieDex UK ASUS TUF GAMING B450M-PLUS II – motherboard – micro ATX – Socket AM4 – AMD B450
ASUS TUF GAMING B450M-PLUS II – Motherboard – micro ATX – Socket AM4 – AMD B450 Chipset – USB-C Gen1, USB 3.2 Gen 1, USB 3.2 Gen 2 – Gigabit LAN – onboard graphics (CPU required) – HD Audio (8-channel)
Basic Specifications
- Manufacturer’s Part Number
- 90MB1620-M0EAY0
- EAN
- 4718017927185
- Product Description
- ASUS TUF GAMING B450M-PLUS II – motherboard – micro ATX – Socket AM4 – AMD B450
- Model
- ASUS TUF GAMING B450M-PLUS II
- Product Type
- Motherboard – micro ATX
- Form Factor
- Micro ATX
- Audio
- HD Audio (8-channel)
- RAM Supported
- 4 DIMM slots – DDR4, non-ECC, ECC, unbuffered
- Compatible Processors
- Ryzen, Athlon (supports 1st,2nd and 3rd Generation Ryzen / Ryzen with Radeon Vega Graphics and 2nd Generation Ryzen with Radeon Graphics / Athlon with Radeon Vega Graphics)
- Max RAM Size
- 128 GB
- Processor Socket
- AMD AM4
- USB / FireWire Ports
- 1 x USB-C Gen 1 + 1 x USB 3.2 Gen 2 + 2 x USB 3.2 Gen 1 + 2 x USB 2.0 + (2 x USB 3.2 Gen 1 + 4 x USB 2.0 via headers)
- Chipset Type
- AMD B450
- Storage Ports
- 6 x SATA-600 (RAID), 1 x M.2
- LAN
- Gigabit Ethernet
Features
- BIOS Type
- AMI
- BIOS Features
- UEFI BIOS, BIOS FlashBack
- Sleep / Wake Up
- Wake on LAN (WOL)
- Hardware Features
- Preboot eXecution Environment (PXE), AMD CrossFireX technology support, TUF LANGuard, audio jack detect technology, jack retasking, Armoury Crate, ASUS Aura Sync, ASUS TurboV EVO, ASUS EPU (Energy Processing Unit), ASUS DIGI+ VRM, ASUS EZ DIY, CrashFree BIOS 3, ASUS Fan Xpert 2+, ASUS TUF Protection, ESD Guards, ASUS Overvoltage Protection, ASUS SafeSlot, ASUS Stainless Steel Back I/O, ASUS Q-Design, Q-DIMM, Q-Slot, TUF Components
General
- Product Type
- Motherboard – micro ATX
- Chipset Type
- AMD B450
- Processor Socket
- Socket AM4
- Max Processors Qty
- 1
- Compatible Processors
- Ryzen, Athlon (supports 1st,2nd and 3rd Generation Ryzen / Ryzen with Radeon Vega Graphics and 2nd Generation Ryzen with Radeon Graphics / Athlon with Radeon Vega Graphics)
Audio
- Type
- HD Audio (8-channel)
- Audio Codec
- Realtek ALC887
- Compliant Standards
- High Definition Audio, DTS Custom
Expansion / Connectivity
- Expansion Slots
- 1 x CPU ¦ 4 x DIMM 288-pin ¦ 1 x PCIe 3.0 x16 (x16 mode (with 1st, 2nd and 3rd Generation Ryzen CPU); x8 mode (with Ryzen with Radeon Vega Graphics and 2nd Generation Ryzen with Radeon Vega Graphics); x4 mode (with Athlon with Radeon Vega Graphics)) ¦ 1 x PCIe 2.0 x1 ¦ 1 x PCIe 2.0 x16 (x4 mode)
- Storage Interfaces
- SATA-600 -connectors: 8 x 7pin Serial ATA – RAID 0 / RAID 1 / RAID 10 ¦ SATA-600 / PCIe 3.0 -connectors: 1 x M.2
- Interfaces
- 1 x LAN (Gigabit Ethernet) ¦ 1 x PS/2 keyboard / mouse ¦ 1 x audio line-in – mini-jack ¦ 1 x audio line-out – mini-jack ¦ 1 x microphone – mini-jack ¦ 2 x USB 2.0 ¦ 1 x HDMI ¦ 1 x DVI-D ¦ 1 x USB 3.2 Gen 2 ¦ 1 x USB-C Gen1 ¦ 2 x USB 3.2 Gen 1
- Internal Interfaces
- 4 x USB 2.0 – header ¦ 2 x USB 3.2 Gen 1 – header ¦ 1 x serial – header ¦ 1 x SPDIF out – header ¦ 1 x audio – header ¦ 1 x speaker – header
- Power Connectors
- 24-pin main power connector, 8-pin ATX12V connector
Miscellaneous
- Included Accessories
- 1 x M.2 screw, I/O back cover, TUF stickers
- Cables Included
- 2 x Serial ATA cable
- Software Included
- Drivers & Utilities, ASUS AI Suite III, ASUS EZ Update, ASUS EZ Flash 3, PC Cleaner, DAEMON Tools, WinRAR, Norton AntiVirus (60 days trial), ASUS TUF GAMING CPU-Z
- Width
- 24.4 cm
- Depth
- 24.4 cm
LAN
- Network Controller
- Realtek RTL8111H
- Network Interfaces
- Gigabit Ethernet
Supported RAM
- Max Size
- 128 GB
- Technology
- DDR4
- Bus Clock
- 2400 MHz, 2133 MHz, 2666 MHz, 2800 MHz (O.C.), 3000 MHz (O.C.), 3200 MHz (O.C.), 3466 MHz (O.C.), 3533 MHz (O.C.), 3400 MHz (O.C.), 3600 MHz (O.C.), 3733 MHz (O.C.), 3866 MHz (O.C.), 4000 MHz (O.C.), 4400 MHz (O.C.)
- Supported RAM Integrity Check
- Non-ECC, ECC
- Registered or Buffered
- Unbuffered
- Features
- Dual channel memory architecture
