Lindy DVI-D to 3G SDI Converter/Extender
- Active video converter
- 1920 x 1080 pixels
- Plug and Play
- Host interface: SDI Output interface: DVI-D
- Silver
The LINDY DVI-D to SDI Converter/Extender allows a DVI-D video signal to be converted for use on SDI displays. Supporting resolutions up to 1080p and with a built-in 3.5mm stereo audio input you can choose between audio from embedded audio in the DVI input or a separate source. This is an ideal product for sending a PC/HD video signal to a SDI display as well as converting DVI signals to 3G-SDI.
| Features | |
|---|---|
| Certification | CE, FCC, REACH & RoHS |
| Product colour | Silver |
| LED indicators | Yes |
| Plug and Play | Yes |
| Converter type | Active video converter |
| Video | |
|---|---|
| Supported video modes | 480i, 576i, 720p, 1080i, 1080p |
| Maximum video resolution | 1920 x 1080 pixels |
| Ports & interfaces | |
|---|---|
| Host interface | SDI |
| Output interface | DVI-D |
| Power | |
|---|---|
| Operating current | 2.6 A |
| Operating voltage | 5 V |
| Operational conditions | |
|---|---|
| Operating relative humidity (H-H) | 20 – 90% |
| Storage temperature (T-T) | -20 – 60 °C |
| Operating temperature (T-T) | 0 – 40 °C |
| Packaging data | |
|---|---|
| Quantity | 1 |
| Quick installation guide | Yes |
| Manual | Yes |
| AC adapter included | Yes |
| Logistics data | |
|---|---|
| Quantity per pack | 1 pc(s) |
