Lenovo ThinkEdge SE50 Intel® Core™ i7 i7-8665UE 16 GB DDR4-SDRAM 512 GB SSD Windows 10 IoT Enterprise Mini PC Black
- Intel Core i7-8665UE (4C/8T, 1.7/4.4GHz, 8MB)
- 1x 16GB SO-DIMM DDR4-2400
- 512GB SSD M.2 2280 PCIe 3.0×4 NVMe Opal
- Intel UHD Graphics 620
- Windows 10 IoT Enterprise 64
Power and reliability at the edge
– Fanless design (0°-50°C operating temperature)
– Diverse I/O port support
– DIN rail, wall mount support
– High-performing computing and memory
– Microsoft® Azure IoT Edge Certified
– AWS IoT Greengrass Certified
| Processor |
| Processor frequency |
1.7 GHz |
| Processor boost frequency |
4.4 GHz |
| Processor threads |
8 |
| Processor cores |
4 |
| Processor model |
i7-8665UE |
| Processor generation |
8th gen Intel® Core™ i7 |
| Processor family |
Intel® Core™ i7 |
| Processor manufacturer |
Intel |
| Memory |
| Memory clock speed |
2400 MHz |
| Memory slots |
2x SO-DIMM |
| Memory layout (slots x size) |
1 x 16 GB |
| Internal memory type |
DDR4-SDRAM |
| Maximum internal memory |
64 GB |
| Internal memory |
16 GB |
| Storage |
| SSD form factor |
M.2 |
| SSD interface |
PCI Express 3.0 |
| NVMe |
Yes |
| SSD capacity |
512 GB |
| Number of SSDs installed |
1 |
| Total SSDs capacity |
512 GB |
| Storage media |
SSD |
| Optical drive type |
No |
| Total storage capacity |
512 GB |
| Graphics |
| On-board graphics card model |
Intel® UHD Graphics 620 |
| On-board graphics card family |
Intel® UHD Graphics |
| On-board GPU manufacturer |
Intel |
| Discrete graphics card model |
Not available |
| On-board graphics card |
Yes |
| Discrete graphics card |
No |
| Network |
| Bluetooth version |
5.1 |
| Bluetooth |
Yes |
| Antenna type |
2×2 |
| WLAN controller model |
Intel Dual Band Wireless-AC 9560 |
| Wi-Fi standards |
Wi-Fi 5 (802.11ac) |
| WLAN controller manufacturer |
Intel |
| Top Wi-Fi standard |
Wi-Fi 5 (802.11ac) |
| Wi-Fi |
Yes |
| Cabling technology |
10/100/1000Base-T(X) |
| Ethernet LAN data rates |
100,1000 Mbit/s |
| Ethernet LAN |
Yes |
| Ports & interfaces |
| Serial ports quantity |
2 |
| Combo headphone/mic port |
Yes |
| Headphone outputs |
1 |
| Ethernet LAN (RJ-45) ports |
2 |
| DisplayPorts quantity |
1 |
| HDMI ports quantity |
1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
2 |
| USB 2.0 ports quantity |
2 |
| Design |
| Product colour |
Black |
| Colour name |
Black |
| Chassis type |
Mini PC |
| Performance |
| Trusted Platform Module (TPM) |
Yes |
| Motherboard chipset |
Intel SoC |
| Product type |
Mini PC |
| Software |
| Operating system architecture |
64-bit |
| Operating system installed |
Windows 10 IoT Enterprise |
| Power |
| Power supply input frequency |
50 – 60 Hz |
| Power supply input voltage |
100 – 240 V |
| Operational conditions |
| Non-operating altitude |
0 – 12192 m |
| Operating altitude |
0 – 3048 m |
| Storage relative humidity (H-H) |
10 – 90% |
| Operating relative humidity (H-H) |
20 – 80% |
| Storage temperature (T-T) |
-40 – 60 °C |
| Operating temperature (T-T) |
10 – 35 °C |
| Certificates |
| Compliance certificates |
RoHS |
| Weight & dimensions |
| Weight |
2.98 kg |
| Height |
72 mm |
| Depth |
182.9 mm |
| Width |
179 mm |
| Packaging content |
| Keyboard included |
Yes |
| Mouse included |
Yes |
| Display included |
No |
