Kingston Technology KSM26ED8/32MF memory module 32 GB 1 x 32 GB DDR4 2666 MHz ECC
- Low-power auto self refresh (LPASR)
- Data bus inversion (DBI) for data bus
- On-die VREFDQ generation and calibration
- Dual-rank
- On-board I2 serial presence-detect (SPD) EEPROM
- Temperature sensor with integrated SPD
- 16 internal banks; 4 groups of 4 banks each
- Selectable BC4 or BL8 on-the-fly (OTF)
| Features |
| JEDEC standard |
Yes |
| Lead plating |
Gold |
| SPD profile |
Yes |
| Programming power voltage (VPP) |
2.5 V |
| Row active time |
32 ns |
| Refresh row cycle time |
350 ns |
| Row cycle time |
45.75 ns |
| Module configuration |
4096M x 72 |
| Memory voltage |
1.2 V |
| Memory ranking |
2 |
| CAS latency |
19 |
| ECC |
Yes |
| Memory form factor |
288-pin DIMM |
| Component for |
PC/Server |
| Memory clock speed |
2666 MHz |
| Internal memory type |
DDR4 |
| Memory layout (modules x size) |
1 x 32 GB |
| Internal memory |
32 GB |
| Buffered memory type |
Unregistered (unbuffered) |
| Operational conditions |
| Storage temperature (T-T) |
-55 – 100 °C |
| Operating temperature (T-T) |
0 – 85 °C |
| Technical details |
| Compliance certificates |
RoHS |
| Sustainability |
| Sustainability compliance |
Yes |
| Weight & dimensions |
| Height |
31.2 mm |
| Width |
133.3 mm |
