Intel Xeon E7530 processor 1.87 GHz 12 MB L3
- Intel® Xeon® 7000 Sequence E7530 1.87 GHz
- 12 MB L3 LGA 1567 (Socket LS)
- Processor cores: 6 45 nm 64-bit 105 W
Designed for maximum performance and reliability, these massively scalable 2-way to 256-way, 64-bit multi-core servers are designed to provide exceptional scalable performance and mission-critical class reliability for your most data-demanding applications and virtualization projects.
Intel® Turbo Boost Technology
Intel® Turbo Boost Technology dynamically increases the processor’s frequency as needed by taking advantage of thermal and power headroom to give you a burst of speed when you need it, and increased energy efficiency when you don’t.
Intel® Hyper-Threading Technology
Intel® Hyper-Threading Technology (Intel® HT Technology) delivers two processing threads per physical core. Highly threaded applications can get more work done in parallel, completing tasks sooner.
Enhanced Intel SpeedStep® Technology
Enhanced Intel SpeedStep® Technology is an advanced means of enabling high performance while meeting the power-conservation needs of mobile systems. Conventional Intel SpeedStep® Technology switches both voltage and frequency in tandem between high and low levels in response to processor load. Enhanced Intel SpeedStep® Technology builds upon that architecture using design strategies such as Separation between Voltage and Frequency Changes, and Clock Partitioning and Recovery.
| Processor |
| Processor ARK ID |
46491 |
| Processor code |
SLBRJ |
| Processor codename |
Nehalem EX |
| Bus type |
QPI |
| VID Voltage Range |
0.675 – 1.35 V |
| Thermal Design Power (TDP) |
105 W |
| Processor cache type |
L3 |
| Processor cache |
12 MB |
| Processor boost frequency |
2.13 GHz |
| Processor operating modes |
64-bit |
| System bus rate |
5.86 GT/s |
| Processor threads |
12 |
| Processor series |
Intel Xeon 7500 Series |
| Cooler included |
No |
| Box |
No |
| Processor lithography |
45 nm |
| Processor socket |
LGA 1567 (Socket LS) |
| Processor cores |
6 |
| Processor base frequency |
1.87 GHz |
| Processor model |
E7530 |
| Processor family |
Intel® Xeon® 7000 Sequence |
| Processor manufacturer |
Intel |
| Features |
| Commodity Classification Automated Tracking System (CCATS) |
NA |
| Export Control Classification Number (ECCN) |
3A991.A.1 |
| Embedded options available |
No |
| Market segment |
Server |
| Execute Disable Bit |
Yes |
| Processor special features |
| Intel VT-x with Extended Page Tables (EPT) |
Yes |
| Intel 64 |
Yes |
| Intel Virtualization Technology (VT-x) |
Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) |
Yes |
| Intel® Turbo Boost Technology |
1.0 |
| Enhanced Intel SpeedStep Technology |
Yes |
| General |
| Product family |
Xeon |
| Operational conditions |
| Tcase |
64 °C |
| Maximum operating temperature |
64 °C |
| Logistics data |
| Harmonized System (HS) code |
8542310001 |
| Technical details |
| Bus bandwidth |
5.86 |
| Bus type units |
GT/s |
| Processor brand name |
Intel Xeon |
| Last change |
63903513 |
| Product family |
Intel Xeon Processor 7000 Sequence |
| Launch date |
Q1’10 |
| Status |
Discontinued |
| Born on date |
Q1’10 |
| Product name |
Intel Xeon E7530 (12M Cache, 1.86 GHz, 5.86 GT/s Intel QPI) |
| Bus speed |
5.86 GT/s |
| Processor cache |
12288 KB |
| Product type |
Processor |
| Other features |
| Cache memory |
12 MB |
