Intel Pentium G3320TE processor 2.3 GHz 3 MB Smart Cache
- Intel Pentium G G3320TE 2.3 GHz
- 3 MB Smart Cache LGA 1150 (Socket H3)
- Processor cores: 2 22 nm 64-bit 35 W
- Maximum internal memory supported by processor: 32 GB DDR3-SDRAM, DDR3L-SDRAM
- On-board graphics card Intel® HD Graphics
A PC with the improved Intel® Pentium® processor unites great performance with everyday tasks. You get reliable PC performance that lets you communicate with friends and family, enjoy entertainment online, and make the most of music and photos. An Intel Pentium processor delivers the Intel-level performance you expect and quality you can count on.
| Processor | |
|---|---|
| Processor ARK ID | 78007 |
| Processor code | SR181 |
| Processor codename | Haswell |
| Memory bandwidth supported by processor (max) | 21.3 GB/s |
| Number of QPI links | 1 |
| Bus type | DMI |
| Stepping | C0 |
| Thermal Design Power (TDP) | 35 W |
| L3 cache speed | 2.3 GHz |
| Processor cache type | Smart Cache |
| Processor cache | 3 MB |
| Processor operating modes | 64-bit |
| System bus rate | 5 GT/s |
| Processor threads | 2 |
| Processor series | Intel Pentium G3000 series for Desktop |
| Component for | PC |
| Cooler included | No |
| Box | No |
| Processor lithography | 22 nm |
| Processor socket | LGA 1150 (Socket H3) |
| Processor cores | 2 |
| Processor base frequency | 2.3 GHz |
| Processor model | G3320TE |
| Processor family | Intel Pentium G |
| Processor manufacturer | Intel |
| Memory | |
|---|---|
| ECC | Yes |
| Memory channels | Dual-channel |
| Memory clock speeds supported by processor | 1333 MHz |
| Memory types supported by processor | DDR3-SDRAM, DDR3L-SDRAM |
| Maximum internal memory supported by processor | 32 GB |
| Graphics | |
|---|---|
| Number of displays supported (on-board graphics) | 3 |
| On-board graphics card dynamic frequency (max) | 1000 MHz |
| On-board graphics card base frequency | 350 MHz |
| On-board graphics card outputs supported | Embedded DisplayPort (eDP), DisplayPort, HDMI, DVI, VGA (D-Sub) |
| Maximum on-board graphics card memory | 1 GB |
| On-board graphics card model | Intel® HD Graphics |
| On-board graphics card | Yes |
| Features | |
|---|---|
| Commodity Classification Automated Tracking System (CCATS) | NA |
| Export Control Classification Number (ECCN) | 3A991 |
| Embedded options available | Yes |
| PCI Express CEM revision | 3.0 |
| Graphics & IMC lithography | 22 nm |
| CPU configuration (max) | 1 |
| Thermal solution specification | PCG 2013A |
| Bandwidth | 5 MB/s |
| Supported instruction sets | SSE4.1, SSE4.2 |
| PCI Express configurations | 1×16, 2×8, 1×8+2×4 |
| PCI Express slots version | 3.0 |
| Maximum number of PCI Express lanes | 16 |
| Market segment | Desktop |
| Execute Disable Bit | Yes |
| Idle States | Yes |
| Thermal Monitoring Technologies | Yes |
| Processor special features | |
|---|---|
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel Secure Key Technology version | 1.00 |
| Intel 64 | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Stable Image Platform Program (SIPP) version | 0.00 |
| Intel Virtualization Technology for Directed I/O (VT-d) | No |
| Intel® Secure Key | Yes |
| Intel TSX-NI | No |
| Intel Enhanced Halt State | Yes |
| Intel® vPro™ Platform Eligibility | No |
| Intel TSX-NI version | 0.00 |
| Conflict-Free processor | Yes |
| Intel Stable Image Platform Program (SIPP) | No |
| Intel® Transactional Synchronization Extensions | No |
| Intel® Hyper Threading Technology (Intel® HT Technology) | No |
| Intel® Turbo Boost Technology | No |
| Intel® AES New Instructions (Intel® AES-NI) | No |
| Intel Trusted Execution Technology | No |
| Intel® Quick Sync Video Technology | Yes |
| Intel® Clear Video HD Technology (Intel® CVT HD) | No |
| Intel® Smart Cache | Yes |
| Enhanced Intel SpeedStep Technology | Yes |
| General | |
|---|---|
| Product family | Pentium |
| Product series | G |
| Operational conditions | |
|---|---|
| Tcase | 72 °C |
| Technical details | |
|---|---|
| End of servicing updates date | Wednesday, June 30, 2021 |
| Servicing status | End of Servicing Lifetime |
| Graphics max dynamic frequency | 1.00 GHz |
| Number of graphics cores | 10 |
| Bus bandwidth | 5 |
| Bus type units | GT/s |
| Processor brand name | Intel Pentium |
| Last change | 63903513 |
| Product family | Intel Pentium Processor |
| Launch date | Q3’13 |
| Status | Launched |
| Born on date | Q3’13 |
| Product name | Intel Pentium G3320TE (3M Cache, 2.30 GHz) |
| Maximum memory | 32 GB |
| Bus speed | 5 GT/s |
| Processor cache | 3072 KB |
| Supported memory types | DDR3-SDRAM, DDR3L-SDRAM |
| Product type | Processor |
| Maximum graphics card memory | 1 GB |
| Logistics data | |
|---|---|
| Harmonized System (HS) code | 85423119 |
| Weight & dimensions | |
|---|---|
| Processor package size | 37.5 x 37.5 mm |
| Other features | |
|---|---|
| Graphics output | eDP/DP/HDMI/DVI/VGA |
| Maximum internal memory | 32 GB |
| Cache memory | 3 MB |
| Intel® Virtualization Technology (Intel® VT) | VT-x |
