iiyama ProLite TF5538UHSC-W1AG computer monitor 139.7 cm (55″) 3840 x 2160 pixels 4K Ultra HD LED Touchscreen Multi-user White
- Touchscreen 139.7 cm (55″) LED IPS
- 4K Ultra HD 3840 x 2160 pixels 16:9
- 60 Hz 8 ms 1100:1
- 120 W
The 4K UHD (3840×2160) Open Frame TF5538UHSC is the ideal interactive display solution for education, kiosks, interactive Digital Signage and in-store communications. The Projective Capacitive (PCAP) touch technology with 12 touch points ensures a seamless and accurate touch response. Featuring a metal housing with 60950-1 ball-drop proof, scratch-resistant, edge-to-edge glass and an IPS panel; this display can be used in landscape, portrait and face-up orientation in the most demanding environments for maximum flexibility and accessibility. Either as a stand-alone wall mounted solution or built-in a desk or kiosk thanks to its Open Frame mounting holes.
Touch technology – Capacitive
This technology uses a sensor-grid of micro-fine wires integrated into the glass that covers the screen. Touch is detected because electrical characteristics of the sensor grid change when human finger is placed on the glass. Thanks to the glass overlay this technology is highly durable, and the touch function remains unaffected even if the glass is scratched. It offers perfect picture performance and will work with human finger (also latex gloved) and stylus-pen.
Open frame
Open frame monitors are an ideal solution for kiosk integrators and Instore Retail.
24/7
24/7 displays are designed for a continues operation.
AG Coating
The Anti Glare coating is used in professional-grade displays to help avoid issues with reflections and external light sources affecting colour reproduction, contrast and sharpness. It also makes the screen less susceptible to dust, grease and dirt marks.
Ball-drop-test proof
The ball-drop-test uses a half-kilo steel ball, which is dropped onto the touch screen from a height of 1.3 meter. If the touch screen surface remains unaffected, the monitor passes the ball-drop-test for high impact resistance and durability.
| Display | |
|---|---|
| Display diagonal (metric) | 139 cm |
| Digital vertical frequency | 23 – 76 Hz |
| Digital horizontal frequency | 30 – 83 kHz |
| Pixel pitch | 0.315 x 0.315 mm |
| Display number of colours | 16.78 million colours |
| Viewing angle, vertical | 178° |
| Viewing angle, horizontal | 178° |
| Maximum refresh rate | 60 Hz |
| Contrast ratio (typical) | 1100:1 |
| Aspect ratio | 16:9 |
| Screen shape | Flat |
| Response time | 8 ms |
| Display brightness | 420 cd/m² |
| Number of simultaneous touchpoints | 12 |
| Touch technology | Multi-touch |
| Touchscreen technology | Projected capacitive system |
| Touchscreen type | Multi-user |
| Panel type | IPS |
| HD type | 4K Ultra HD |
| Touchscreen | Yes |
| Display technology | LED |
| Native aspect ratio | 16:9 |
| Display resolution | 3840 x 2160 pixels |
| Display diagonal | 139.7 cm (55″) |
| Performance | |
|---|---|
| Operating hours (hours/days) | 24/7 |
| AMD FreeSync | No |
| NVIDIA G-SYNC | No |
| Multimedia | |
|---|---|
| RMS rated power | 16 W |
| Number of speakers | 2 |
| Built-in speaker(s) | Yes |
| Design | |
|---|---|
| Glass thickness | 4 mm |
| Housing material | Metal |
| Product colour | White |
| Ports & interfaces | |
|---|---|
| RS-232 ports | 1 |
| HDCP | Yes |
| Audio output | Mini jack |
| Audio input | Mini jack |
| DisplayPorts quantity | 1 |
| HDMI ports quantity | 2 |
| HDMI | Yes |
| VGA (D-Sub) ports quantity | 1 |
| USB Touch port | Yes |
| Network | |
|---|---|
| Ethernet LAN | Yes |
| Ergonomics | |
|---|---|
| Plug and Play | Yes |
| Number of OSD languages | 8 |
| On Screen Display (OSD) languages | German, Dutch, English, Spanish, French, Italian, Polish, Russian |
| Wall mountable | Yes |
| Panel mounting interface | 600 x 400 mm |
| VESA mounting | Yes |
| Power | |
|---|---|
| Power supply type | AC |
| AC input frequency | 50 Hz |
| AC input voltage | 100 – 240 V |
| Power consumption (standby) | 1 W |
| Power consumption (typical) | 120 W |
| Operational conditions | |
|---|---|
| Storage temperature (T-T) | -20 – 60 °C |
| Operating temperature (T-T) | 0 – 40 °C |
| Weight & dimensions | |
|---|---|
| Weight (without stand) | 41 kg |
| Height (without stand) | 765.5 mm |
| Depth (without stand) | 68 mm |
| Width (without stand) | 1294.5 mm |
| Packaging data | |
|---|---|
| Package height | 930 mm |
| Package depth | 245 mm |
| Package width | 1400 mm |
| Packaging content | |
|---|---|
| Batteries included | Yes |
| Quick start guide | Yes |
| Remote control included | Yes |
| Cables included | AC, DisplayPort, HDMI, IR, USB |
| General | |
|---|---|
| Product family | ProLite |
| Other features | |
|---|---|
| Energy efficiency class (old) | A |
| Certification | CB, CE, TÜV-Bauart, CU, cULus |
| Placement supported | Horizontal/Vertical |
| Display viewable area (HxV) | 1209.6 x 680.4 mm |
| International Protection (IP) code | IP54 |
| Logistics data | |
|---|---|
| Harmonized System (HS) code | 85285210 |
