Cisco C9130AXI-D wireless access point 5380 Mbit/s White Power over Ethernet (PoE)
- 2.4 GHz
- 5 GHz
- Maximum data transfer rate: 5380 Mbit/s
- Power over Ethernet (PoE)
- Internal
With the emergence of high-density networks and the Internet of Things (IoT), we are more dependent on wireless networks than ever before. Increasing numbers of devices connect to the network every year, ranging from high-performance client devices to low-bandwidth IoT devices. Cisco Catalyst 9130AX Series Access Points provide a seamless experience anywhere for everyone, with high scaling and unmatched performance in diverse network deployments. Going beyond the Wi-Fi 6 (802.11ax) standard, the 9130AX Series provides integrated security, resiliency, and operational flexibility as well as increased network intelligence.
Extending Cisco’s intent-based network and perfect for networks of all sizes, the Cisco Catalyst 9130AX Series scales to meet the growing demands of IoT while fully supporting the latest innovations and new technologies. The 9130AX Series is also a leader in performance, security, and analytics.
The Cisco Catalyst 9130AX Series Access Points, paired with the Cisco Digital Network Architecture (Cisco DNA), are enterprise-class products that will address both your current and future needs. They are the first step in updating your network to take better advantage of all of the features and benefits that Wi-Fi 6 provides.
Features |
Dynamic Frequency Selection (DFS) |
Yes |
Cyclic Shift Diversity (CSD) |
Yes |
Maximal-Ratio Combining (MRC) |
Yes |
MIMO type |
Multi User MIMO |
MIMO |
Yes |
Bluetooth version |
5.0 |
Bluetooth |
Yes |
Ethernet LAN data rates |
100,1000,2500,5000 Mbit/s |
Maximum data transfer rate |
5380 Mbit/s |
5 GHz |
Yes |
2.4 GHz |
Yes |
Ports & interfaces |
USB 2.0 ports quantity |
1 |
Ethernet LAN (RJ-45) ports |
2 |
Power |
Power over Ethernet (PoE) |
Yes |
Design |
Product colour |
White |
Antenna |
Antenna gain level (max) |
6 dBi |
Antenna direction type |
Omni-directional |
Antenna type |
Internal |
Performance |
Flash memory |
1024 MB |
Internal memory |
2048 MB |
Weight & dimensions |
Weight |
1.45 kg |
Height |
48 mm |
Depth |
226 mm |
Width |
226 mm |
Operational conditions |
Non-operating altitude |
0 – 4600 m |
Operating altitude |
0 – 3000 m |
Storage temperature (T-T) |
-30 – 70 °C |
Operating temperature (T-T) |
0 – 50 °C |
Operating relative humidity (H-H) |
10 – 90% |
