Axis COMPANION CUBE LW IP security camera Indoor 1920 x 1080 pixels Wall
- Indoor IP security camera
- CMOS 25.4 / 3 mm (1 / 3″) 2 MP 1920 x 1080 pixels
- Wireless Wi-Fi
- Night vision 10 m IR
- Cube Wall
- White
- 128 g
– Indoor full HD IR wireless network camera
– Wireless communication with support for a/b/g/n
– High video quality in HDTV 1080p and 2 MP resolution
– Built-in IR illumination for surveillance in total darkness
– WDR to handle scenes with complex light conditions
– Built-in microphone, mini-speaker and PIR motion sensor
– Bracket for wall and corner mount
– AXIS Companion Card 63 GB included
– 3 year warranty
Easiest set-up for 1-2 camera solution
AXIS Companion Cube LW together with AXIS Companion Card 64 GB makes a self-contained recording solution. Through wireless communication with AXIS Companion software and apps, this is the easiest set up for a smaller surveillance solution.
Please note!
AXIS Companion IP cameras are supported only by AXIS Companion video management software and mobile apps for iOS and Android devices.
Smart design for indoor surveillance
AXIS Companion Cube LW features high quality video in HDTV 1080p/2 MP resolution and WDR. It comes with IR illumination, day/night functionality, PIR motion sensor, microphone and mini-speaker. The camera connects over wireless LAN (IEEE 802.11a/b/g/n) or wired Ethernet. It supports Wi-Fi Protected Setup™ with push button configuration. AXIS Companion Cube LW is optimized for edge storage and with AXIS Companion Card 64 GB included it is a self-contained recording solution. Axis Zipstream technology allows even high quality video to be recorded effectively. AXIS Companion Cube LW is supported only by AXIS Companion video management software and mobile app.
| Performance | |
|---|---|
| Certification | EN 55032 Class B, EN 61000-3-2, EN 61000-3-3, EN 55024, EN 61000-6-1, EN 61000-6-2, FCC Part 15 Subpart B Class B, ICES-003 Class B, VCCI Class B, RCM AS/NZS CISPR 32 Class B, KN24, KN-35EN 300328, EN 301489-1, EN 301489-17, EN 301893,FCC Part 15 Subpart C, FCC Part 15 Subpart E, RSS-247IEC/EN/UL 60950-1, IEC/EN 62471, EN 62471 |
| Languages support | Simplified Chinese, Traditional Chinese, German, English, Spanish, French, Italian, Japanese, Portuguese, Russian |
| Detachable antenna(s) | No |
| Antenna type | Internal |
| Antennas quantity | 1 |
| Alarm input/output | Yes |
| Infrared (IR) cut-off filter | Yes |
| Day/night mode | Yes |
| Wide Dynamic Range (WDR) | Yes |
| Connectivity technology | Wireless |
| Placement supported | Indoor |
| Type | IP security camera |
| Design | |
|---|---|
| Product colour | White |
| Mounting type | Wall |
| Form factor | Cube |
| Camera | |
|---|---|
| Camera shutter speed | 1/25000 – 1/5 s |
| Lens viewing angle, vertical | 61° |
| Lens viewing angle, horizontal | 110° |
| Angle of rotation | 180° |
| Minimum illumination | 0.05 lx |
| Image sensor | |
|---|---|
| Progressive scan | Yes |
| Optical sensor size | 25.4 / 3 mm (1 / 3″) |
| Sensor type | CMOS |
| Lens system | |
|---|---|
| Fixed focal length | 2.8 mm |
| Night vision | |
|---|---|
| LED type | IR |
| Night vision distance | 10 m |
| Night vision | Yes |
| Video | |
|---|---|
| Image quality adjustment | Brightness, Contrast, Sharpness |
| Full HD | Yes |
| Frame rate | 30 fps |
| Supported video modes | 240p, 1080p |
| Supported graphics resolutions | 320 x 240, 1920 x 1080 (HD 1080) |
| Video compression formats | H.264, M-JPEG |
| Video formats supported | H.264, M-JPEG |
| Total megapixels | 2 MP |
| Maximum resolution | 1920 x 1080 pixels |
| Audio | |
|---|---|
| Built-in microphone | Yes |
| Audio formats supported | AAC |
| Audio system full duplex | No |
| Network | |
|---|---|
| Frequency band | 2.4, 5 GHz |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g |
| Wi-Fi | Yes |
| Storage | |
|---|---|
| Flash memory | 256 MB |
| Compatible memory cards | MicroSD (TransFlash) |
| Card reader integrated | Yes |
| Ports & interfaces | |
|---|---|
| Interface | WLAN |
| Security | |
|---|---|
| Video motion detection | Yes |
| Motion sensor | Yes |
| HTTPS encryption | Yes |
| Security algorithms | WPA, WPA2, WPA2-PSK |
| Management features | |
|---|---|
| Remotely operated | Yes |
| Power | |
|---|---|
| Power consumption (max) | 5 W |
| Power consumption (typical) | 2.7 W |
| Operational conditions | |
|---|---|
| Operating relative humidity (H-H) | 10 – 85% |
| Storage temperature (T-T) | -40 – 65 °C |
| Operating temperature (T-T) | 0 – 40 °C |
| Weight & dimensions | |
|---|---|
| Weight | 128 g |
| Height | 106 mm |
| Depth | 37 mm |
| Width | 60 mm |
| Packaging content | |
|---|---|
| Number of cameras | 1 |
| Technical details | |
|---|---|
| Lens mount interface | M12 |
| Colour | Yes |
| Internet connection required | Yes |
| Video resolutions | 320 x 240,1920 x 1080 pixels |
