Axis 02114-001 security camera Covert IP security camera Indoor 640 x 480 pixels Wall
- Built-in analytics; Outdoor-ready, discreet sensor unit; Reliable and budget-friendly detection; Thermal technology for low false alarm rate; Two variants with a choice of lenses
AXIS P1280-E is a cost-effective indoor/outdoor thermal camera that ensures reliable detection with a low rate of false alarms. The camera can be used as a surveillance sensor that doesn’t compromise personal integrity. It features a choice of lenses to meet your specific requirements; a 2.2 mm lens for wide-angle views and a 4 mm lens for narrower views with longer detection distances. AXIS P1280-E comes with built-in analytics as well as support for AXIS Perimeter Defender and 3rd party analytics. The flexible and highly discreet design allows for versatile installation: behind surfaces for discreet surveillance, on walls, or recessed.
| Performance | |
|---|---|
| Connectivity technology | Wired |
| Placement supported | Indoor |
| Type | IP security camera |
| Design | |
|---|---|
| Housing material | Polycarbonate (PC) |
| Product colour | White |
| Mounting type | Wall |
| Form factor | Covert |
| Camera | |
|---|---|
| Lens viewing angle, vertical | 47° |
| Lens viewing angle, horizontal | 63° |
| Lens system | |
|---|---|
| Lens diameter | 2.2 mm |
| Number of lenses | 1 |
| Video | |
|---|---|
| Text caption overlay | Yes |
| Time stamp overlay | Yes |
| Gain control type | Auto |
| Video streaming | Yes |
| Frame rate | 8.3 fps |
| Video compression formats | H.264, M-JPEG |
| Maximum resolution | 640 x 480 pixels |
| Network | |
|---|---|
| Supported network protocols | IPv4, IPv6 USGv6, HTTP, HTTPSa , SSL/TLSa , QoS Layer 3 DiffServ, FTP, CIFS/SMB, SMTP, Bonjour, UPnPTM, SNMPv1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, SFTP, TCP, UDP, IGMPv1/v2/v3, RTCP, ICMP, DHCP, ARP, SOCKS, SSH, LLDP, MQTT v3.1.1 |
| Networking standards | IEEE 802.3af, IEEE 802.3at |
| Ethernet LAN | Yes |
| Storage | |
|---|---|
| Flash memory | 256 MB |
| Compatible memory cards | MicroSD (TransFlash), MicroSDHC, MicroSDXC |
| Card reader integrated | Yes |
| HDD capacity | 0.5 GB |
| Built-in HDD | Yes |
| Ports & interfaces | |
|---|---|
| Ethernet LAN (RJ-45) ports | 1 |
| Security | |
|---|---|
| IP address filtering | Yes |
| HTTPS encryption | Yes |
| Mirror | Yes |
| Security algorithms | EAP-TLS, HTTPS |
| Alert notification type | E-mail, Snapshot alert message |
| Pixel counter | Yes |
| Password protection | Yes |
| Power | |
|---|---|
| Power consumption (Power over Ethernet (PoE)) | 2.5 W |
| Power consumption (max) | 4 W |
| Power consumption (typical) | 2.5 W |
| Power source type | PoE |
| Operational conditions | |
|---|---|
| Operating relative humidity (H-H) | 10 – 100% |
| Storage temperature (T-T) | -40 – 65 °C |
| Operating temperature (T-T) | -30 – 55 °C |
| Weight & dimensions | |
|---|---|
| Weight | 72 g |
| Height | 109 mm |
| Depth | 46 mm |
| Width | 16 mm |
| Packaging content | |
|---|---|
| Number of cameras | 1 |
| Logistics data | |
|---|---|
| Harmonized System (HS) code | 85258900 |
