Axis 01929-001 security camera Bullet IP security camera Indoor & outdoor 2592 x 1944 pixels Ceiling/wall
- 30 fps in 5 MP or up to 180 fps in HDTV 720p; ATEX, IECEx, EAC Ex, IA and PESO; Lightfinder and Forensic WDR; Signed firmware and secure boot; Zipstream supporting H.264 and H.265
Certified (ATEX, IECEx, EAC Ex, IA and PESO) for use in potentially combustible environments, this lightweight camera offers high quality, high resolution images of people and objects. Featuring Axis Lightfinder and Axis Forensic WDR, it delivers true colors and great details in challenging light or near darkness. It includes electronic image stabilization for stable images despite vibration. And, intelligent i-CS lens technology facilitates fast and easy installation with remote zoom. Built-in cybersecurity features such as signed firmware and secure boot ensure the integrity and authenticity of the firmware. Furthermore, Axis Zipstream with support for H.264/H.265 significantly lowers bandwidth and storage requirements.
| Performance | |
|---|---|
| Certification | EMCEN 55035, EN 55032 Class A, EN 61000-3-2, EN 61000-3-3,EN 61000-6-1, EN 61000-6-2EnvironmentIEC/EN 60529 IP68NetworkNIST SP500–267ExplosionEN/IEC 60079-0, EN/IEC 60079-1, EN/IEC 60079-31,TR CU 012/2011, GOST R IEC 60079-0, GOST IEC 60079-1,GOST R IEC 60079-31;Model key: T08-VA2.3.K3.BOR2-LL.H-005.N-PATEX: II 2 G Ex db IIC T5 Gb, II 2 D Ex tb IIIC T95°C DbCertificate: TÜV 18 ATEX 8218XIECEx: Ex db IIC T5 Gb, Ex tb IIIC T95°C DbCertificate: IECEx TUR 18.0023XIA: Ex db IIC T5 Gb, Ex tb IIIC T95°C DbCertificate: MASC MS/18-3256XEAC Ex: 1Ex db IIC T5 Gb, Ex tb IIIC T 95°C DbSeries: T8, Model: T08-VA2.3.Certificate: RU C-DE.AБ61.В.00381/19PESO: Ex db IIC T5 GbCertificate: A/P/HQ/KA/104/5735 |
| Languages support | Simplified Chinese, Traditional Chinese, German, English, Spanish, French, Italian, Japanese, Korean, Polish, Portuguese, Russian |
| Built-in heater | Yes |
| Number of languages | 12 |
| Dynamic range | 120 dB |
| Processor model | ARTPEC-7 |
| Remote viewing | Yes |
| Day/night mode | Yes |
| Wide Dynamic Range (WDR) | Yes |
| PTZ modes | Digital PTZ |
| PTZ control | Yes |
| Connectivity technology | Wired |
| Placement supported | Indoor & outdoor |
| Type | IP security camera |
| Design | |
|---|---|
| International Protection (IP) code | IP68 |
| Protection features | Explosion proof |
| Housing material | Stainless steel |
| Product colour | Stainless steel |
| Mounting type | Ceiling/wall |
| Form factor | Bullet |
| Camera | |
|---|---|
| Camera shutter speed | WDR: 1/33500 s to 1/5 s |
| Lens viewing angle, vertical | 55 – 23° |
| Lens viewing angle, horizontal | 75 – 31° |
| Image sensor | |
|---|---|
| Progressive scan | Yes |
| Optical sensor size | 25.4 / 2.7 mm (1 / 2.7″) |
| Sensor type | CMOS |
| Lens system | |
|---|---|
| Focus adjustment | 1.5 |
| Focal length range | 3.9 – 10 mm |
| Optical zoom | 2.6x |
| Zoom capability | Yes |
| Number of lenses | 1 |
| Night vision | |
|---|---|
| Night vision | Yes |
| Video | |
|---|---|
| Image stabilizer | Yes |
| Video streaming | Yes |
| Frame rate | 180 fps |
| Video recording | Yes |
| Supported video modes | 720p |
| Supported graphics resolutions | 1280 x 720 (HD 720), 2592 x 1944, 2688 x 1520 |
| Video compression formats | H.264, H.265 |
| Video formats supported | H.264, H.265 |
| Total megapixels | 5 MP |
| Maximum resolution | 2592 x 1944 pixels |
| Network | |
|---|---|
| Supported network protocols | IPv4, IPv6 USGv6, ICMPv4/ICMPv6, HTTP, HTTPSa , HTTP/2, TLSa , QoS Layer 3 DiffServ, FTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP™, SNMP v1/v2c/v3 (MIB-II), DNS/DNSv6, DDNS, NTP, RTSP, RTP, SRTP, SFTP, TCP, UDP, IGMP, RTCP, ICMP, DHCPv4/v6, ARP, SOCKS, SSH, LLDP, CDP, MQTT v3.1.1, Syslog, Link-Local address (ZeroConf) |
| Bluetooth | No |
| Wi-Fi | No |
| Ethernet LAN | Yes |
| Storage | |
|---|---|
| Flash memory | 512 MB |
| Maximum memory card size | 128 GB |
| Compatible memory cards | MicroSDXC |
| Card reader integrated | Yes |
| Built-in HDD | No |
| Ports & interfaces | |
|---|---|
| Ethernet LAN (RJ-45) ports | 1 |
| Security | |
|---|---|
| HTTPS encryption | Yes |
| Security algorithms | EAP-TLS, HTTPS |
| Alert notification type | |
| Pixel counter | Yes |
| Password protection | Yes |
| Power | |
|---|---|
| Power consumption (Power over Ethernet (PoE)) | 5.4 W |
| Power consumption (max) | 10.7 W |
| Power source type | PoE |
| Operational conditions | |
|---|---|
| Storage relative humidity (H-H) | 5 – 95% |
| Operating relative humidity (H-H) | 10 – 100% |
| Storage temperature (T-T) | -40 – 65 °C |
| Operating temperature (T-T) | -60 – 60 °C |
| Weight & dimensions | |
|---|---|
| Weight | 7.8 kg |
| Length | 334 mm |
| Diameter | 11.3 cm |
| Height | 160.5 mm |
| Packaging content | |
|---|---|
| Packaging content | Installation Guide, Windows®decoder 1-user license, SKDP03-TCable ExCam 5 meter, AXIS Surveillance microSDXC Card 128 GB |
| Included memory card size | 128 GB |
| Memory card included | MicroSDXC |
| Number of cameras | 1 |
| Other features | |
|---|---|
| Doesn’t contain | BFR, PVC |
