ASUS PCE-AX1800 BT5.2 Internal WLAN / Bluetooth 1775 Mbit/s
- Next-Gen WiFi Standard – WiFi 6 (802.11ax) standard for better efficiency and throughput.
- Ultrafast WiFi Speed -1800 Mbps WiFi speed to handle even the busiest network with ease.
- 802.11ax technology -With OFDMA and MU-MIMO, WiFi 6 enables more efficient, stable, and faster transmission even when multiple devices are transmitting data at the same time.
- Bluetooth 5.2 for faster, further coverage – Bluetooth 5.2 not only allows to transfer data up to twice as fast as before, and with 4X the range, it also lengthens the battery, and improves the audio quality.
- The Latest WPA3 Network Security —providing your PC with an extra layer of protection against external attacks to give you added peace of mind.
1.5X Faster WiFi, Even in Crowded Networks
With WiFi 6 (802.11ax) technology, ASUS PCE-AX1800 delivers wireless speeds that are up to 1.5X faster than WiFi 5 (802.11ac) devices. A revolutionary combination of OFDMA and MU-MIMO technologies ensures the most efficient WiFi connection for your PC.
PCE-AX1800 only supports PCI-Express x1 standard, please install the adapter in PCI-e x1 slot.
Still Fast, Even In Crowded Network
ASUS PCE-AX1800 pairs trusted MU-MIMO connectivity and innovative OFDMA technology to efficiently allocate bandwidth and communicate with multiple devices simultaneously. The upshot is smoother WiFi connections and the fastest attainable speeds for all devices*.
*Disclaimer: MU-MIMO supported router and client required
Instant Bluetooth Upgrade – Faster Speed and better audio quality
Slot ASUS PCE-AX1800 into your PC for an instant upgrade to the latest Bluetooth 5.2 technology. Bluetooth 5.2 not only allows to transfer data up to twice as fast as before, and with 4X the range, it also lengthens the battery, and improves the audio quality.
The Latest WPA3
Network Security
ASUS PCE-AX1800 comes with the latest WPA3 Wi-Fi security standard, providing your PC with an extra layer of protection against external attacks to give you added peace of mind.
| Ports & interfaces | |
|---|---|
| Interface | WLAN / Bluetooth |
| Host interface | PCI Express |
| Connectivity technology | Wireless |
| Network | |
|---|---|
| Bluetooth version | 5.2 |
| Bluetooth | Yes |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax) |
| Top Wi-Fi standard | Wi-Fi 6 (802.11ax) |
| Wi-Fi band | Dual-band (2.4 GHz / 5 GHz) |
| Wi-Fi | Yes |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Maximum data transfer rate | 1775 Mbit/s |
| Design | |
|---|---|
| Antenna | Yes |
| Antenna design | External |
| Component for | PC |
| Internal | Yes |
| System requirements | |
|---|---|
| Windows operating systems supported | Windows 10 x64 |
| Weight & dimensions | |
|---|---|
| Weight | 49.4 g |
| Height | 22 mm |
| Depth | 88 mm |
| Width | 120 mm |
| Packaging data | |
|---|---|
| Package weight | 250 g |
| Package height | 50 mm |
| Package depth | 138 mm |
| Package width | 180 mm |
| Logistics data | |
|---|---|
| Harmonized System (HS) code | 85176990 |
