Asrock Phantom Gaming RX 6500 XT 8GB OC AMD Radeon RX 6500 XT GDDR6
- AMD Radeon RX 6500 XT 8 GB GDDR6
- 7680 x 4320 pixels 64 bit PCI Express x8 4.0
- HDMI ports quantity: 1 DisplayPorts quantity: 1
- DirectX version: 12 Ultimate OpenGL version: 4.6
- 1x 8-pin
AMD Radeon RX 6500 XT Phantom Gaming 8GB
- Clock: GPU / Memory
- Boost Clock: Up to 2825 MHz / 18 Gbps
- Game Clock: Up to 2685 MHz / 18 Gbps
- Base Clock: 2420 MHz / 18 Gbps
- 6nm AMD Radeon RX 6500 XT
- 8GB GDDR6
- AMD RDNA 2 Architecture
- DirectX 12 Ultimate
- PCI Express 4.0 Support
- 1 x 8-pin Power Connector
- 1 x DisplayPort 1.4 with DSC
- 1 x HDMI 2.1 VRR
- Dual Fan Design
- Stylish Metal Backplate
- Striped Axial Fan
- 0dB Silent Cooling
- Super Alloy Graphics Card
- ASRock Tweak 2.0
- AMD FidelityFX Super Resolution
- Hardware Raytracing
Dual Fan Design
Two fans that provide strong cooling performance and make your gaming rig stay cool. It’s optimized for delivering excellent gaming experience with stylish and streamlined design.
Striped Axial Fan
Designed For Enhanced Airflow.
ASRock’s custom Striped Axial Fan delivers enhanced airflow to optimize cooling from not only the stripe structure on each fan blade but also the polishing surface on the bottom side.
Stylish Metal Backplate
With the Phantom Gaming look, the stylish metal backplate on the Phantom Gaming graphics cards makes it more fancy in visual and solid in construction. Otherwise, the thermal pad at the backside also helps to enhance the thermal efficiency.
0dB Silent Cooling
Spin For Cooling, Stop For Silence.
The fan spins when the temperature goes high for the optimal cooling, and stops when the temperature goes low for the complete silence.
Nano Thermal Paste
Perfect Thermal Teamwork.
Eliminate the gaps in the contact area to maximize heat transfer and thermal efficiency.
Premium Thermal Pad
Better Heat Transfer.
The premium thermal pad helps to transfer the heat of the components to the heatsink, improving heat dissipation.
Precise Screw Torque
Optimized Mounting Pressure.
ASRock adopts precise screw torque when assembling its graphics cards to optimize the cooler mounting pressure to improve thermal efficiency while avoiding damage to GPU die.
Super Alloy Graphics Card
Dr. MOS
Dr.MOS is the integrated power stage solution which is optimized for synchronous buck-set down voltage applications! Intelligently delivering higher current and driving up to 50A continuous current for each phase, thus providing improved thermal result and superior performance.
Premium 90A Power Choke
Compared to traditional chokes, ASRock’s premium 90A power chokes effectively make the saturation current up to three times better, thus providing enhanced and improved Vcore voltage to the graphics card.
Matte Black PCB
A new mysterious matte black and copper color scheme to match the prestigious components on ASRock’s high-end graphics card.
High Density Glass Fabric PCB
High Density Glass Fabric PCB design that reduces the gaps between the PCB layers to protect the graphics card against electrical shorts caused by humidity.
ASRock Tweak 2.0
Pro and Easy-to-Use Tuning Utility.
Provides the smart fan speed control and instant performance tweaking.
8K Resolution Support
Not only can it handles 4K graphics but also supports the next generation 8K video output for the ultimate visual experience.
PCI Express 4.0 Support
This graphics card features PCI Express 4.0 support, with a throughput of 16 GT/s and enables two times the bandwidth compared to PCI Express 3.0. Get ready for the next generation of PC gaming.
| Processor | |
|---|---|
| Stream processors | 1024 |
| Processor boost clock speed (Gaming mode) | 2685 MHz |
| Processor boost clock speed | 2825 MHz |
| Processor frequency | 2420 MHz |
| CUDA | No |
| Maximum resolution | 7680 x 4320 pixels |
| Graphics processor | Radeon RX 6500 XT |
| Graphics processor family | AMD |
| Memory | |
|---|---|
| Memory bandwidth (max) | 18 GB/s |
| Memory bus | 64 bit |
| Graphics card memory type | GDDR6 |
| Discrete graphics card memory | 8 GB |
| Ports & interfaces | |
|---|---|
| DisplayPort version | 1.4a |
| HDMI version | 2.1 |
| DisplayPorts quantity | 1 |
| HDMI ports quantity | 1 |
| Interface type | PCI Express x8 4.0 |
| Performance | |
|---|---|
| Dual Link DVI | No |
| HDCP | Yes |
| OpenGL version | 4.6 |
| DirectX version | 12 Ultimate |
| Design | |
|---|---|
| Product colour | Multicolour |
| Number of fans | 2 fan(s) |
| Cooling type | Active |
| Power | |
|---|---|
| Supplementary power connectors | 1x 8-pin |
| Minimum system power supply | 400 W |
| Weight & dimensions | |
|---|---|
| Height | 129 mm |
| Depth | 42 mm |
| Length | 240 mm |
| Weight | 459 g |
| Packaging data | |
|---|---|
| Package type | Box |
| General | |
|---|---|
| Product family | Phantom Gaming |
